YT-01 Thermal-Safe Electric Lift Table
This YT-01 model emphasizes protected motor operation for institutional and public-sector office projects. Integrated thermal and electronic protection support dependable daily adjustment, while the clean white frame and configurable packaging help project suppliers deliver consistent workstation programs. Technical figures are reference values subject to final order approval.
Key Advantages
Thermal protection helps safeguard motor operation
Electronic overload protection supports reliable use
Simple controls suit shared administrative workstations
Project labels, manuals and inspection support available
Suitable for tenders, contract orders and container supply
Product Attributes
| 1. Model | YT-01 |
|---|
| 2. Category | Single Motor Standing Desk |
|---|
| 3. Product Type | Thermal-protected electric lift table |
|---|
| 4. Drive System | Upgraded single motor |
|---|
| 5. Lifting Columns | Two steel columns |
|---|
| 6. Support Layout | Four-point floor support |
|---|
| 7. Height Adjustment | Electric continuous lift |
|---|
| 8. Thermal Protection | Integrated |
|---|
| 9. Overload Protection | Electronic |
|---|
| 10. Reference Height Range | Approx. 720-1200 mm |
|---|
| 11. Reference Speed | Approx. 20 mm/s |
|---|
| 12. Reference Capacity | Up to 70 kg |
|---|
| 13. Noise Level | Typically below 50 dB |
|---|
| 14. Basic Handset | Up/down controller |
|---|
| 15. LED Display | Optional |
|---|
| 16. Memory Presets | Optional |
|---|
| 17. Anti-Collision | Optional |
|---|
| 18. Soft Start/Stop | Supported |
|---|
| 19. Input Voltage | 100-240 V AC |
|---|
| 20. Frequency | 50/60 Hz |
|---|
| 21. Duty Cycle | Reference 10% |
|---|
| 22. Standby Mode | Low-power |
|---|
| 23. Frame Material | Cold-rolled steel |
|---|
| 24. Surface Finish | Powder coating |
|---|
| 25. Standard Color | White |
|---|
| 26. Optional Colors | Black, gray or custom |
|---|
| 27. Desktop Material | MDF, MFC or particleboard |
|---|
| 28. Desktop Width | Approx. 1000-1600 mm |
|---|
| 29. Desktop Depth | Approx. 500-800 mm |
|---|
| 30. Reference Desktop | 1200 x 600 mm |
|---|
| 31. Frame Width | Fixed or telescopic |
|---|
| 32. Feet | T-shaped steel feet |
|---|
| 33. Leveling Pads | Adjustable |
|---|
| 34. Cable Management | Optional tray and grommets |
|---|
| 35. Assembly | Knock-down |
|---|
| 36. Installation Kit | Manual and hardware |
|---|
| 37. Packaging | Export carton with foam |
|---|
| 38. Tender Labels | Asset, PO and department labels available |
|---|
| 39. OEM Branding | Available |
|---|
| 40. Documentation | Customized manuals and packing records |
|---|
| 41. Sample Service | Available |
|---|
| 42. Main Application | Public-sector offices, administration departments and institutions |
|---|
| 43. Target Buyers | Tender suppliers, traders and contract furniture companies |
|---|
| 44. Order Scale | Project and container quantities |
|---|
| 45. Specification Note | Final protection functions follow approved controller configuration |
|---|
Institutional Supply Support
Project buyers can specify department labels, standardized manuals, spare hardware packs and inspection documents for phased public-sector office installations.
